AD1 200

AD1 SERIES

AD1 perfectly fits ADIVA mission: to offer vehicles with the highest level of SAFETY and PROTECTION

AD1 200

Adiva Advanced Vehicles

AD1 means a great STABILITY and excellent road holding in all weather conditions, SECURITY on all road surfaces, including rail-tracks, pebbles and manholes that may also be found in large cities.

AD1 is equipped with the patented MODULAR PROTECTION SYSTEM. AD3 front suspension, combined with an excellent chassis, ensures an easy and precise turn-in

COLOR
Engine Transmission
Engine

PeugeotEngine Water-cooled 4 cycles/OHC 4-valves Liquid Engine

Bore / Stroke

64mm x 58.8mm

Displacement

190 cm³

Max power

14kW / 8,500rpm

Max torque

Nm / 6,900rpm

Fuel system

Injection

Starter system

Self-start

Fuel Capacity

7.5L

Trasmissione

CVT

Wheels & Frame
Tyres

Front 130/60 x 13», rear 150/70 x 13» tubeless

Rims

5 spokes aluminium rims, front 3.50 x 13», rear 4.00 x 13»

Front Brake

Double 220 mm disc brake

Rear Brake

240 mm disc brake

Frame

High-resistance steel pipe and traily mixed frame

Front Suspensions

Single two-ways shock absorber

REAR SUSPENSIONS

Engine behaving structural, double rear two-ways shock absorbers preload adjustable on 5 positions

Sizes
LENGTH

2,062 mm

WIDTH

650 mm

HEIGHT

1,670 mm

SEAT HEIGHT

720 mm

WHEEL BASE

1,490 mm

DRY WEIGHT

204 kg

GASOLINE TANK

12,2 litres (2,0 litres reserve)
