AD3 400

AD3 SERIES

AD3 perfectly fits ADIVA mission: to offer vehicles with the highest level of SAFETY and PROTECTION

AD3 400

Adiva Advanced Vehicles

AD3 means a great STABILITY and excellent road holding in all weather conditions, SECURITY on all road surfaces, including rail-tracks, pebbles and manholes that may also be found in large cities.

AD3 is equipped with the patented MODULAR PROTECTION SYSTEM. AD3 front suspension, combined with an excellent chassis, ensures an easy and precise turn-in

COLOR
  • White
  • Graphite
Engine Transmission
Engine

PeugeotEngine Water-cooled 4 cycles/OHC 4-valves Liquid Engine

Bore / Stroke

84mm x 72mm

Displacement

399 cc

Max power

27.4kw / 7,250rpm

Max torque

38.1Nm / 5,500rpm

Fuel system

Injection

Starter system

Self-start

Fuel Capacity

11L

Trasmissione

CVT

Wheels & Frame
Tyres

Front 130/60 x 13», rear 150/70 x 13» tubeless

Rims

5 spokes aluminium rims, front 3.50 x 13», rear 4.00 x 13»

Front Brake

Double 220 mm disc brake

Rear Brake

240 mm disc brake

Frame

High-resistance steel pipe and traily mixed frame

Front Suspensions

Single two-ways shock absorber

REAR SUSPENSIONS

Engine behaving structural, double rear two-ways shock absorbers preload adjustable on 5 positions

Sizes
LENGTH

2,175 mm

WIDTH

820 mm

HEIGHT

1,770 mm

SEAT HEIGHT

770 mm

WHEEL BASE

1,560 mm

DRY WEIGHT

257 kg

GASOLINE TANK

12,2 litres (2,0 litres reserve)
